2025
Kawasaki
Mule 4010 Trans4x4
Stock #KD00142
71 people have recently viewed it.
Status:
NewVehicle:
2025 Kawasaki Mule 4010 Trans4x4VIN:
JK1ATCB14STD00142Model Number:
KAT620BSFNNColor:
Dark Royal RedStock Number:
KD00142Title:
ClearLocation:
Ehlerding MotorsportsWarranty:
Manufacturer's w/ Extended Available
BRAKES
Front Brake Type:
Sealed Hydraulic DrumRear Brake Type:
Sealed Hydraulic Drum
DRIVE LINE
Differential Lock Location:
RearDriveline Type:
Selectable 4X2 / 4X4Limited Slip Differential Location:
FrontNumber Of Driveline Modes:
2Rear Unlocking Differential:
Yes
ENGINE
Bore (in):
2.99Bore (mm):
76Carburetion Brand:
MikuniCarburetion Type:
Fuel InjectedCompression Ratio:
10.3Cooling:
LiquidCylinders:
2Displacement (cc):
617Displacement (ci):
37.6Engine Stroke:
4-StrokeEngine Type:
V TwinFuel Injector Size (mm):
34Fuel Injector:
YesFuel Requirements:
RegularFuel Type:
GasSpeed Governor:
YesStarter:
ElectricStroke (in):
2.68Stroke (mm):
68Torque (Ft Lbs):
34.7Torque (Nm):
47Torque RPM:
2500Valve Configuration:
OHVValves Per Cylinder:
2Valves:
4
EXTERIOR
Bash Plate (Front):
YesBody Material:
PlasticBrush Guard:
YesFrame:
SteelFront Mud Guards:
YesRadiator Guard:
YesRear Mud Guards:
Yes
INSTRUMENTATION
LIGHTS
SEATS
Folding:
YesNumber Of Rows:
2Number Of Seats:
4Seat Material:
VinylSeat Type:
Bench
STEERING
Steering Control:
Steering WheelSteering Type:
Power
STORAGE
Bed Capacity (kgs.):
362.9Bed Capacity (lbs.):
800Bed Height (in):
11.2Bed Height (mm):
284.5Bed Length (in):
50.4Bed Length (mm):
1280.2Bed Volume (ft3):
10.2Bed Volume (m3):
0.3Bed Width (in):
47.6Bed Width (mm):
1209Cargo Bed Material:
SteelCargo Bed Tilt:
YesIntegral Tie-Down Hooks:
YesNumber Of Cupholders:
2
SUSPENSION
TECHNICAL SPECIFICATIONS
Fuel Capacity (gal):
6.3Fuel Capacity (l):
23.8Ground Clearance (in):
7.1Ground Clearance (mm):
180.3Height (in):
75.8Height (mm):
1925.3Length (ft):
10.71Length (ft/ft):
10Length (ft/in):
8.5Length (in):
128.5Length (mm):
3263.9Payload Capacity (kgs):
603.3Payload Capacity (lbs):
1330Towing Capacity (kgs):
544.3Towing Capacity (lbs):
1200Turning Radius (ft):
12.8Wet Weight (kg):
720Wet Weight (lbs):
1587.6Wheelbase (in):
85.2Wheelbase (mm):
2164.1Width (in):
58.5Width (mm):
1485.9
TRANSMISSION
Hi / Low Range:
YesPrimary Drive (Engine / Transmission):
BeltPrimary Drive (Front Wheel):
ShaftPrimary Drive (Rear Wheel):
ShaftReverse:
YesTransmission Type:
Continuously Variable (CVT)
WHEELS & TIRES
Prices exclude freight & destination charges, dealer assembly & prep, documentation fees, and applicable tax & title fees.
The ePrice for this 2025 Kawasaki Mule 4010 Trans4x4 is only $0!
